DFRobot Gravity I2C HUB, 8 ports, passive distribution board, I2C, UART
Product number: DFR0759
CHF 2.20
Available · 39 piece · 2-5 Tage
CHF 2.20
Customers also bought
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 11 piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Description
Product information "DFRobot Gravity I2C HUB, 8 ports, passive distribution board, I2C, UART"
The DFRobot Gravity: I2C HUB module is a distribution board for expanding the I2C interface for microcontroller-based projects. It enables the parallel connection of up to eight I2C devices to a single controller, which facilitates the development of modular and sensor-based applications. Compatible Gravity modules can be connected directly via special Gravity-4P I2C/UART sensor cables, while conventional breakout modules can be integrated via standard jumper cables.
The module serves as a passive interface distribution for I2C communication and is particularly suitable for projects with multiple sensors. Areas of application include IoT systems, data-based acquisition with Arduino or Raspberry Pi as well as robotics-related or educational applications. The simple plug-in connection with gravity cables supports quick integration into existing systems, while the connection option for standard modules allows flexible adaptation to individual requirements.
The board is used to operate several I2C components simultaneously without manually distributing the communication via a bus. The function is to pass on the I2C signal from the microcontroller to up to eight end devices. Integration takes place either via standardised 4-pin gravity sensor cables or via individual jumper cables. In simple terms, it is a distributor piece that enables several sensors or modules to be operated simultaneously via the same data connection.
Features at a glance
- Connection option for up to eight I2C devices
- Support for Gravity-4P I2C/UART sensor cables
- Compatible with breakout modules via jumper cables
- Colour-coded pins for quick orientation: red (VCC), black (GND), green (SDA), blue (SCL)
- Four mounting holes for mechanical fastening
- Arduino
- Raspberry Pi
- Gravity-compatible sensors and modules
- Breakout boards with I2C interface
- Dimensions: 27 x 37 mm
- Weight: 17 g
- Passive distribution board for I2C communication
- Four mounting holes for easy installation
- Colour-coded connections: VCC (red), GND (black), SDA (green), SCL (blue)
- 1x Gravity: I2C HUB
- 1x Gravity-4P I2C/UART sensor cable
Properties
| Zolltarifnummer: | 84733080 |
|---|---|
| Brand: | DFRobot |
| Country of Origin: | China |
| Gross Weight (kg): | 0.100 |
| Manufacturer ID: | DFR0759 |
| Product ID: | DFR0759 |
