SparkFun PicoBuck LED Driver
Product number: COM-13705
CHF 17.90
Available · 5 piece · 2-5 Tage
CHF 17.90
Customers also bought
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 14 piece · 2-5 Tage
Available · 1 piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 13 piece · 2-5 Tage
Available · 23 piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 44 piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 61 piece · 2-5 Tage
Available · 28 piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 94 piece · 2-5 Tage
Available · 6 piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Description
Product information "SparkFun PicoBuck LED Driver"
Three signal inputs are available for dimming control. You can use the PWM signal from an Arduino or your favourite microcontroller to dim each channel individually, or you can tie them all to the same PWM for simultaneous dimming. Dimming can be done by analogue voltage (20%-100% of maximum current by varying the voltage from .5V-2.5V) or by PWM (as long as the PWM minimum voltage is less than .4V and the maximum voltage is greater than 2.4V) for a full 0-100% range. There is a small jumper for each channel that allows you to increase the drive current from 330mA to 660mA. On both sides of the board there are two mounting holes for 4-40 or M3 screws. They are perforated so that they can be easily snapped off with pliers if a smaller footprint is desired.
Note: The PicoBuck LED driver was produced in collaboration with Ethan Zonca. A portion of each sale is returned to him.
Documents:
Properties
| Zolltarifnummer: | 85423190 |
|---|---|
| Brand: | SparkFun |
| Country of Origin: | USA |
| EAN: | 5904422334185 |
| Gross Weight (kg): | 0.005 |
| Manufacturer ID: | COM-13705 |
| Product ID: | COM-13705 |
Manufacturer and safety information
SparkFun Electronics
6333 Dry Creek Parkway
DE CO 80503 Niwot
https://www.sparkfun.com
support@sparkfun.com
WEEE number: 17968585
Responsible person for the EU
Sertronics GmbH
Am Studio 20d
DE 12489 Berlin
https://www.berrybase.de
info@berrybase.de
Safety instructions
- Do not use the LED controller in damp or wet environments unless it is expressly labelled as waterproof.
- Only operate with the specified operating voltage and current to avoid damage or short circuits.
- Do not use damaged cables or plugs to avoid the risk of electric shock or fire.
- Avoid direct sunlight or extreme heat to prevent the appliance from overheating.
- Children and untrained persons may only use the appliance under supervision.
- To prevent injury or damage, do not open or tamper with the appliance during operation.
- In the event of a defect or malfunction, disconnect the appliance and have it checked by qualified personnel.
- For disposal: Do not dispose of in household waste, but recycle in accordance with local regulations for electronic waste or hand in at collection points.
- Ensure that batteries (if used) are separated and disposed of properly.
- During intensive use, always ensure adequate ventilation to prevent heat build-up.
