SparkFun Qwiic - Atmospheric Sensor Breakout, BME280
Product number: SEN-15440
CHF 15.35
Available · 7 piece · 2-5 days
CHF 15.35
Customers also bought
Content: 10 Meter (CHF 0.11 / 1 Meter)
Available · 100+ piece · 2-5 days
Available · 24 piece · 2-5 days
Available · 76 piece · 2-5 days
Available · 5 piece · 2-5 days
Available · 9 piece · 2-5 days
Available · 9 piece · 2-5 days
Content: 10 Meter (CHF 0.11 / 1 Meter)
Available · 67 piece · 2-5 days
Available · 13 piece · 2-5 days
Available · 100+ piece · 2-5 days
Available · 100+ piece · 2-5 days
Available · 100+ piece · 2-5 days
Available · 100+ piece · 2-5 days
Content: 10 Meter (CHF 0.11 / 1 Meter)
Available · 80 piece · 2-5 days
Description
Product information "SparkFun Qwiic - Atmospheric Sensor Breakout, BME280"
The BME280 on-board sensor measures barometric pressure from 30kPa to 110kPa as well as relative humidity and temperature. The breakout offers a 3.3V SPI interface, a 5V-tolerant I2C interface (with pull-up resistors to 3.3V) and can be configured to take measurements with less than 1mA current consumption.
Features:
- Operating voltage: 1.71V-3.6V(standard for Qwiic system: 3.3V)
- I2C & SPI interface
- Temperature range
- Overall accuracy: 0°C-65°C (32°F-149°F)
- Operational: -40°C-85°C (-40°F-185°F)
- Humidity range: 0-100% RH
- Pressure range: 300-1100 hPa (30,000-110,000 Pa or approx. 4.35-15.95 PSI)
- I2C address: 0x77 (default) or 0x76
Properties
| Zolltarifnummer: | 85423911 |
|---|---|
| Brand: | SparkFun |
| Country of Origin: | USA |
| EAN: | 5904422352134 |
| Gross Weight (kg): | 0.002 |
| Manufacturer ID: | SEN-15440 |
| Product ID: | SEN-15440 |
Manufacturer and safety information
SparkFun Electronics
6333 Dry Creek Parkway
DE CO 80503 Niwot
https://www.sparkfun.com
support@sparkfun.com
WEEE number: 17968585
Person responsible for the EU
Sertronics GmbH
Am Studio 20d
DE 12489 Berlin
https://www.berrybase.de
info@berrybase.de
Safety instructions
- Read the operating instructions carefully before commissioning and operate the product in accordance with the specifications.
- Protect the product from moisture, dust and extreme heat.
- Avoid direct contact with conductive liquids to prevent short circuits.
- Do not use in potentially explosive atmospheres unless expressly authorised.
- Do not touch or mechanically damage the sensor element.
- Do not use the device if there are any noticeable changes in operation or damage.
- Dispose of in accordance with local environmental regulations for electronic components.
- Do not dispose of electronic waste with household waste, but take it to a recycling centre.
