Waveshare 1.69 inch round LCD display, 240x280, IPS, touchscreen, SPI/I2C, 3.3V-5V
Product number: WS-27057
CHF 15.35
Available · 6 piece · 2-5 Tage
CHF 15.35
Customers also bought
Available · 68 piece · 2-5 Tage
Available · 20 piece · 2-5 Tage
Available · 13 piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 20 piece · 2-5 Tage
Available · 43 piece · 2-5 Tage
Available · 39 piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 25 piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 80 piece · 2-5 Tage
Available · 91 piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 6 piece · 2-5 Tage
Description
Product information "Waveshare 1.69 inch round LCD display, 240x280, IPS, touchscreen, SPI/I2C, 3.3V-5V"
Features at a glance
- 240×280 resolution and 262K colours provide a clear and colourful display.
- Highly transparent touch screen with fast response and long life.
- Built-in ST7789V2 driver chip and CST816T capacitive touch control chip, utilises SPI and I2C communication.
- Operating voltage: 3.3V / 5V
- Resolution: 240 × 280 pixels
- Display driver: ST7789V2
- Touch driver: CST816T
- Display interface: 4-wire SPI
- Touch interface:
- I2C
- Display panel: IPS
- Touch type: Capacitive
- Display size: 27.972 × 32.634mm
- Pixel size: 0.11655 × 0.11655mm
- Module size: 33.13 × 41.13mm
- Interfaces:
- SPI and I2C control interfaces
- On-board voltage translator compatible with 3.3V / 5V input
- PIN connections and compatibility with Raspberry Pi, ESP32S3, Pico, Arduino, STM32 etc.
- 1x 1.69 inch touch LCD module
- 1x GH1.25 12Pin cable
Properties
| Zolltarifnummer: | 85437009 |
|---|---|
| Brand: | Waveshare |
| Country of Origin: | China |
| Gross Weight (kg): | 0.374 |
| Manufacturer ID: | 1.69inch Touch LCD Module |
| Product ID: | WS-27057 |
Manufacturer
Waveshare
Waveshare: High quality modules for your Raspberry Pi
Waveshare is a reliable specialist when it comes to displays, cameras and other modules for your Raspberry Pi. With the products of the innovative electronics expert, you can turn your computer into a true all-round device.
Waveshare provides an optimal view
You are looking for the ideal display module for your Raspberry Pi? At Berrybase you will find a wide range of products from Waveshare. Each display and all associated modules have been designed with the utmost precision and meet the highest demands - no matter what purpose the respective product is supposed to serve.
For example, the Waveshare ePaper HATs offer perfect conditions if you want a high display quality even in strong sunlight. A big advantage of ePaper displays is their extremely low energy consumption. The best example is the 2.13" 250×122 ePaper Display HAT with integrated controller, which is optimally tailored to the Raspberry Pi 2B, 3B, Zero and Zero W. The communication with this module is done via SPI interface. The ePaper display equipped with the HAT is limited to the colors black and white and reflects light like conventional paper. This is good for the display quality.
If you prefer a display in the three colors red, black and white to complement your Raspberry Pi, the 2.7" 264×176 ePaper Display HAT is recommended. It has the same technical features as the other Waveshare ePaper HATS.
Compact and of brilliant quality: The Waveshare 7 inch Display
The Waveshare 7 inch display, on the other hand, scores not only with its compact design, but also with a 1024x600 hardware resolution and capacitive touch control. On all devices with Raspberry Pi OS, the 7 inch LCD even works driver-free. The integrated 3.5mm jack enables sound output, while the image is produced via an HDMI connection. The impeccable quality manifests itself in a high-quality glass surface with a 6H hardness level.
At Berrybase, you can get the display including a robust case on request - so that it is optimally protected against external influences. Besides the Waveshare 7 inch display, the electronics specialist also has many other screens in different sizes available.
Waveshare Game HAT: Turning your Raspberry Pi into a game console
One of the top sellers at Berrybase is the Waveshare Game HAT for the Raspberry Pi. The controller transforms your computer into a mobile game console. The 3.5" IPS display convinces with a 480×320 resolution and ensures smooth image playback and thus unlimited gaming fun. The sound is reproduced via on-board speakers or optionally via the 3.5 mm jack socket. The battery of the Game HAT is charged via the integrated charging circuit. The module is compatible with the Raspberry Pi models A+, B+, 2B, 3B and 3B+. For other versions the connection via HDMI cable is possible.
If you want to turn your Raspberry Pi into a mobile retro console, we recommend the GamePi43 with a 4.3-inch IPS display, which is suitable for the Raspberry Pi models B+, 2B, 3B and 3B+, or the especially compact GamePi20. The latter features a 2.0-inch IPS display and is compatible with the Raspberry Pi Zero 1.3, Zero W as well as the Zero WH.
Practical accessories for every purpose
By the way: Waveshare's product range is also peppered with useful accessories for your Raspberry Pi. The Li-Ion battery HAT for example provides a mobile power supply for your computer. The 8 channel DIN rail relay module from Waveshare allows you to use your Raspberry Pi as a control module for tech projects in the home, for example to centrally control the home lighting or shutters. And with the Ethernet / USB HUB HAT, Waveshare has designed a module that extends the USB capability of your Raspberry Pi and provides an RJ45 Ethernet port. The latter offers an enormous added value when a stable wired Ethernet connection is required.
Manufacturer and safety information
Waveshare International Limited
2F, World Trade Plaza south side, Fuhong Rd
CN 518033 Futian District, Shenzhen
https://www.waveshare.com
support@waveshare.com
WEEE number: 72769965
Person responsible for the EU
Sertronics GmbH
Am Studio 20d
DE 12489 Berlin
https://www.berrybase.de
info@berrybase.de
Safety instructions
- Keep away from children and unauthorised persons.
- Do not expose to direct sunlight or extreme temperatures.
- Protect from mechanical stress such as pressure or impact.
- Do not allow any liquids to get onto the product.
- Avoid electrostatic discharges, observe ESD protection measures.
- Only operate with the intended voltage and in accordance with the manufacturer's instructions.
- Discontinue use immediately in the event of damage or malfunction.
- Do not dispose of with household waste, but observe electronic waste regulations.
- Dispose of in an environmentally friendly manner in accordance with regional regulations.
- To avoid damage, do not open or modify the device yourself.
