Waveshare industrial USB 3.2 hub: 4-port extension, switchable dual hosts, multiple protection
Product number: WS-23929
CHF 24.45
Available · 20 piece · 2-5 Tage
CHF 24.45
Customers also bought
Available · 88 piece · 2-5 Tage
Available · 63 piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 10 piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 6 piece · 2-5 Tage
Available · 37 piece · 2-5 Tage
Available · 20 piece · 2-5 Tage
Available · 100+ piece · 2-5 Tage
Available · 48 piece · 2-5 Tage
Available · 13 piece · 2-5 Tage
Available · 82 piece · 2-5 Tage
Description
Product information "Waveshare industrial USB 3.2 hub: 4-port extension, switchable dual hosts, multiple protection"
Discover the industrial USB hub that will revolutionise your workspace. With 4x USB 3.2 ports, it expands your connection options and simultaneously supports two hosts that can be easily switched at the touch of a button. This is ideal for industrial and office environments with demanding device requirements.
This innovative solution enables the sharing of USB devices between two different hosts, such as a computer and a Raspberry Pi. Control both hosts seamlessly with just one keyboard and mouse. The highlight: your desk remains free of unnecessary device chaos.
This hub not only offers multiple protection and maximum reliability, but also a space-saving and tidy working environment. It is ideal for anyone who values order, efficiency and optimised device usage.
Features at a glance
- 4 extended USB ports, switchable between two inputs, sharing USB devices between two hosts
- Industrial hub chip with MTT technology for stable and consistent 4-port USB connections
- ESD protection for each USB port to prevent electrical surge damage and data loss
- Overvoltage protection to prevent damage from high voltage inputs
- Multiple protection circuits: Overcurrent, short circuit, overheating, reverse current, undervoltage lockout, 8KV ESD protection, filter protection, etc.
- Industrial metal housing, robust and durable, with mounting holes for easy installation
- Standard: High-speed USB 3.2 Gen 1
- Data rate: up to 5 Gbps
- USB output: 5V at maximum 1.2A, USB-A connection
- USB hub input: 5V, switchable dual USB-A ports (independent power supply, no crossed power)
- External power supply: DC power supply port 7~36V (additional power supply required when connected to high power devices)
- Operating environment: -40℃ to 85℃
- Supported operating systems: Mac OS (8.6 or higher), Linux (2.4.20 or higher), Windows 11 / 10 / 8.1 / 8 / 7 / XP
- 1x USB3.2 Gen1 HUB-2IN-4OUT
- 2x dual USB3.0 cable connector
Properties
| Zolltarifnummer: | 84718000 |
|---|---|
| Brand: | Waveshare |
| Compatibility: | Raspberry Pi 5, Raspberry Pi 4B, Raspberry Pi 3B+, Raspberry Pi Zero WH, Raspberry Pi Compute 4, Raspberry Pi 3B, Raspberry Pi 3A+, Raspberry Pi Zero W, Raspberry Pi Zero, Raspberry Pi 400 |
| Country of Origin: | China |
| EAN: | 4060137083020 |
| Gross Weight (kg): | 0.232 |
| Manufacturer ID: | USB3.2-Gen1-HUB-2IN-4OUT |
| Product ID: | WS-23929 |
Manufacturer
Waveshare
Waveshare: High quality modules for your Raspberry Pi
Waveshare is a reliable specialist when it comes to displays, cameras and other modules for your Raspberry Pi. With the products of the innovative electronics expert, you can turn your computer into a true all-round device.
Waveshare provides an optimal view
You are looking for the ideal display module for your Raspberry Pi? At Berrybase you will find a wide range of products from Waveshare. Each display and all associated modules have been designed with the utmost precision and meet the highest demands - no matter what purpose the respective product is supposed to serve.
For example, the Waveshare ePaper HATs offer perfect conditions if you want a high display quality even in strong sunlight. A big advantage of ePaper displays is their extremely low energy consumption. The best example is the 2.13" 250×122 ePaper Display HAT with integrated controller, which is optimally tailored to the Raspberry Pi 2B, 3B, Zero and Zero W. The communication with this module is done via SPI interface. The ePaper display equipped with the HAT is limited to the colors black and white and reflects light like conventional paper. This is good for the display quality.
If you prefer a display in the three colors red, black and white to complement your Raspberry Pi, the 2.7" 264×176 ePaper Display HAT is recommended. It has the same technical features as the other Waveshare ePaper HATS.
Compact and of brilliant quality: The Waveshare 7 inch Display
The Waveshare 7 inch display, on the other hand, scores not only with its compact design, but also with a 1024x600 hardware resolution and capacitive touch control. On all devices with Raspberry Pi OS, the 7 inch LCD even works driver-free. The integrated 3.5mm jack enables sound output, while the image is produced via an HDMI connection. The impeccable quality manifests itself in a high-quality glass surface with a 6H hardness level.
At Berrybase, you can get the display including a robust case on request - so that it is optimally protected against external influences. Besides the Waveshare 7 inch display, the electronics specialist also has many other screens in different sizes available.
Waveshare Game HAT: Turning your Raspberry Pi into a game console
One of the top sellers at Berrybase is the Waveshare Game HAT for the Raspberry Pi. The controller transforms your computer into a mobile game console. The 3.5" IPS display convinces with a 480×320 resolution and ensures smooth image playback and thus unlimited gaming fun. The sound is reproduced via on-board speakers or optionally via the 3.5 mm jack socket. The battery of the Game HAT is charged via the integrated charging circuit. The module is compatible with the Raspberry Pi models A+, B+, 2B, 3B and 3B+. For other versions the connection via HDMI cable is possible.
If you want to turn your Raspberry Pi into a mobile retro console, we recommend the GamePi43 with a 4.3-inch IPS display, which is suitable for the Raspberry Pi models B+, 2B, 3B and 3B+, or the especially compact GamePi20. The latter features a 2.0-inch IPS display and is compatible with the Raspberry Pi Zero 1.3, Zero W as well as the Zero WH.
Practical accessories for every purpose
By the way: Waveshare's product range is also peppered with useful accessories for your Raspberry Pi. The Li-Ion battery HAT for example provides a mobile power supply for your computer. The 8 channel DIN rail relay module from Waveshare allows you to use your Raspberry Pi as a control module for tech projects in the home, for example to centrally control the home lighting or shutters. And with the Ethernet / USB HUB HAT, Waveshare has designed a module that extends the USB capability of your Raspberry Pi and provides an RJ45 Ethernet port. The latter offers an enormous added value when a stable wired Ethernet connection is required.
Manufacturer and safety information
Waveshare International Limited
2F, World Trade Plaza south side, Fuhong Rd
CN 518033 Futian District, Shenzhen
https://www.waveshare.com
support@waveshare.com
WEEE number: 72769965
Person responsible for the EU
Sertronics GmbH
Am Studio 20d
DE 12489 Berlin
https://www.berrybase.de
info@berrybase.de
Safety instructions
- Only use the USB hub in dry indoor areas and protect it from moisture.
- Do not expose the USB hub to direct sunlight, extreme temperatures or mechanical stress.
- Do not overload the USB hub; observe the maximum current load of the device and connected devices.
- Avoid improper handling such as pulling on the cable or improper insertion/removal of USB plugs.
- Only clean the product with a dry or slightly damp cloth, do not use water or harsh chemicals.
- Dispose of the USB hub in accordance with local regulations for electronic waste, do not dispose of it with household waste.
- Keep out of the reach of children to prevent accidental misuse.
- Ensure that the connected power supply unit (if available) is compatible and does not cause overvoltage.
- In the event of damage such as cable breakage or visible defects, take the appliance out of operation immediately.
- Only use the USB hub with compatible devices to avoid data loss or damage.
